Latitude 14 3000 Series (3460/3470) Latitude 14 3000 Series (3480)
Processor 5th Gen (BDW) and 6th Gen Intel® Skylake ULT processors 6th Gen (Skylake) and 7th Gen Intel® Kaby Lake ULT processors
Operating System Windows 7; Windows 8.1; Windows 10, Linux Ubuntu, Neokylin Windows 7 (TBD); Windows 10, Linux Ubuntu
CMF /
Dimensions /
Weight Polycarbonate plastics, painted for improved wear resistance
342x 243.2 x 22.2 mm (non-touch)
342x 243.2 x 22.6 mm (touch)
4.23 lbs. / 1.92kg (entry battery) Polycarbonate plastics, textured (better scratch resistance)
337.4.0 x 244 x 23.3mm
3.87 lbs. / 1.77kg (entry battery)
Display 14.0” HD (1366 X 768), Anti-Glare
14.0” FHD (1920 X 1080), Anti-Glare
14.0” HD (1366 X 768) Touchscreen 14.0” HD (1366 X 768), Anti-Glare
14.0” FHD (1920 X 1080), Anti-Glare
14.0” HD (1366 X 768) Touchscreen
Graphics Intel Integrated GT2; optional nVidia 2GB Discrete Intel Integrated GT2; optional AMD 2GB Discrete
Memory DDR3L, 1600MHz, Two slots up to 16GB DDR4, 2133MHz, Two slots up to 16GB
Battery 40WHr and 65WHr Cylindrical batteries (latch in the back) 42WHr and 56WHr Prismatic batteries (behind door)
Primary Storage Up to 1TB HDD; 500GB SSHD and 128GB SSD Up to 1TB HDD; up to 256GB SSD; extra M.2 32GB SSD (cache)
Optical Drives No optical drive No internal optical drive
Connectivity DW 1802 2x2 AGN; Intel 3165 1x1 AC; Intel 8260 2x2 AC
Integrated Ethernet 10/100/1000 (GbE); No WWAN DW 1810 1x1 802.11ac (BT+WLAN combo)
DW 1820 2x2 802.11ac (BT + WLAN combo)
Intel 8265 2x2 802.11ac (BT + WLAN combo)
Integrated Ethernet 10/100/1000 (GbE); optional WWAN
Multimedia Integrated HD webcam with Single microphone;
optional IR camera (Touch configs) Integrated HD webcam with Single microphone;
optional IR camera (Touch configs)
Ports and Slots (2) USB 3.0 + (1) USB 2.0, RJ45 Ethernet, HDMI, VGA,
4-1 SD card,
Universal headset, K-Security Lock, AC Power In (1) USB 3.0 + (1) USB 3.0 w/PowerShare, (1) USB 2.0,
RJ-45, HDMI, VGA, 4-1 SD card, audio jack, Noble wedge lock, AC Power In
